CreeperLeaf USB-RS485
Industrial-grade isolated USB to RS485/RS422 converter.
The CreeperLeaf USB-RS485 is a robust, galvanically isolated USB to RS485/RS422 converter built for demanding industrial environments. It enables reliable half-duplex RS485 and full-duplex RS422 communication through any standard USB port, with plug-and-play support across Windows, macOS, Linux, and Android.
Key Specs
Technical Specifications
| Communication | |
| Interface | RS-485 / RS-422 |
| USB Version | USB 2.0 Full Speed (12 Mbps) |
| Max Data Rate | 256 Kbps |
| Duplex Mode | Half-duplex (RS-485) / Full-duplex (RS-422) |
| Connector (USB) | Type-C |
| Connector (RS-485) | Screw terminal |
| Isolation | |
| Isolation Type | Galvanic (optical) |
| Isolation Voltage | 2500 V RMS |
| Operating Conditions | |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +125°C |
| Humidity | 5% to 95% non-condensing |
| Mechanical | |
| Enclosure | Aluminum alloy |
| Dimensions | 72 × 26 × 16 mm |
| Weight | 48 g |
| Compatibility | |
| OS Support | Windows 7/10/11, macOS, Linux, Android |
| Driver | Auto-install (no driver needed on modern OS) |
